TIL: Testing Secure Zeroization in Zig with Custom Memory Allocators

While spending the summer learning Zig I have come to love and appreciate one of the language’s core philosophies: what you see is what you get.

In Zig, there’s no operator overloading and memory allocations are always explicit. Simply reading the code should reveal exactly what your software is instructing the computer to do. If a library allocates memory, the idiomatic approach is to accept a memory allocator as an input, so callers can pick the memory management strategy that matches the end use-case.

There are exceptions,¹ and other languages have reasons they allow such abstractions, but I’ve enjoyed working in this style. It aligns well with my current interests and experience. When I return to other, more “sugary”, languages, using Zig has improved my feel for where the “hidden” allocations and functionality are.

An idea begins to form

#

In particular, this is useful for testing that your custom memory management strategies are, actually, working. My first “real” Zig project, the Zecrecy library, zeros out sensitive data before freeing the memory to mitigate the impact of Heartbleed-style vulnerabilities.

Because Zig is explicit and its docs are still maturing, you are reading the standard library’s source code by the time you build much more than “hello world”.² I’d read the code for the std.mem.Allocator interface, along with several of the allocator implementations in the standard library, so I felt confident enough to try it when the idea popped into my head: a custom allocator that panics if asked to free non-zero memory.

Of course, this is not a novel idea. I learned it from the Zig Standard Library’s testing Allocator, a nifty implementation that takes advantage of Zig’s memory management paradigm. In testing, use std.testing.allocator when a call requests a memory allocator. The test will panic if the allocator detects any memory leaks during testing.³

To improve Zecrecy’s testing quality, I wrote ZerosOnlyAllocator. It’s pretty simple, it wraps a child allocator to handle the actual allocations. This has a couple benefits:

1. I don’t have to write my own allocation logic just for a bit of testing, and
2. If the child allocator is std.testing.allocator, then I get memory-leak detection in the same test run!

The core “functionality” lies in the free() function:

/// Panics if the memory is not zeroed before freeing.
fn free(
    ctx: *anyopaque,
    buf: []u8,
    alignment: mem.Alignment,
    ret_addr: usize
) void {
    const self: *ZerosOnlyAllocator = @ptrCast(@alignCast(ctx));
    for (buf) |byte| {
        if (byte != 0) @panic("non-zero byte freed");
    }
    self.child_allocator.rawFree(buf, alignment, ret_addr);
}

I love this kind of thing because it only gains value the more tests I add. Test setup is only three lines:

const ZerosOnlyAllocator = @import("testing/ZerosOnlyAllocator.zig");
var zeros_only_allocator: ZerosOnlyAllocator = .init(std.testing.allocator);
const allocator = zeros_only_allocator.allocator();

Now, every single test automatically verifies our core security guarantee with zero additional effort.

Debugging detour

#

Except! The first time I ran unit tests using the shiny, new, custom allocator, every single test panicked:

~/zecrecy> zig test src/secret.zig
thread 3381248 panic: non-zero byte freed
~/zecrecy/src/testing/ZerosOnlyAllocator.zig:59:24: 0x104dbc753 in free (test)
        if (byte != 0) @panic("non-zero byte freed");
                       ^
~/.cache/zig/p/N-V-__8AAPWKhxNMNK6YniIioDpRryBzI7DMp0hJB4rExlGU/lib/std/mem/Allocator.zig:147:25: 0x10236238f in free__anon_5332 (test)
    return a.vtable.free(a.ptr, memory, alignment, ret_addr);
                        ^
~/zecrecy/src/secret.zig:120:34: 0x10235e12b in deinit (test)
            secret.allocator.free(secret.data);

Turns out, my assumption that reading the standard library once makes one an expert was, unsurprisingly, wrong. The custom allocator’s logic was correct, but the standard library contained some unexpected functionality that broke my assumptions:

/// From `std.mem.Allocator`:
///
/// Free an array allocated with `alloc`.
/// If memory has length 0, free is a no-op.
/// To free a single item, see `destroy`.
pub fn free(self: Allocator, memory: anytype) void {
    const Slice = @typeInfo(@TypeOf(memory)).pointer;
    const bytes = mem.sliceAsBytes(memory);
    const bytes_len = bytes.len +
                      if (Slice.sentinel() != null) @sizeOf(Slice.child) else 0;
    if (bytes_len == 0) return;
    const non_const_ptr = @constCast(bytes.ptr);
    @memset(non_const_ptr[0..bytes_len], undefined);
    self.rawFree(non_const_ptr[0..bytes_len], .fromByteUnits(Slice.alignment), @returnAddress());
}

All tests panicked because std.mem.Allocator.free⁴ writes undefined into freed memory before calling .rawFree. In Debug and ReleaseSafe modes Zig fills undefined bytes with a debug pattern (0xAA) to catch use-after-free bugs,⁵ which meant my test allocator saw non-zero bytes.

The solution? Bypass the layer altogether and call .rawFree() directly.⁶ Now, we can verify zeroization at the layer closest to deallocation.

And boom! All tests pass:

~/zecrecy> zig test src/secret.zig
All 15 tests passed.

With each one, I can feel a tiny bit better knowing all secrets were actually zeroed before they were freed.

Conclusion

#

The effort required was low for the value gained, I’ve barely scratched the surface of using custom memory allocators to improve testing.⁷ Reducing the “black box” opaqueness that sometimes hangs like a fog over unit tests is a nice tool to have. I’m optimistic that Zig’s upcoming async/IO changes will provide similar opportunities to get surgical during testing.

And, of course, building test harnesses that enforce application invariants is far from unique to Zig. It’s a powerful technique with demonstrated value. Zig’s win, for me, is in making every decision explicit and shoving the reality of an implementation into your face at all times. You naturally think deeper about how to wield the verbosity in your favor.

Have any cool, weird, or otherwise nerdy uses you’ve gotten out of Zig’s memory management explicitness? Do you have a favorite method for testing your system’s security guarantees? Send me an email or a message!
